Replace Palette

Match image to a palette then remap it to another palette.

Node Data
Display name
Replace Palette
Internal name
Node_Color_replace
Inheritances
Node_Processor
Node_Color_replace
Inputs
toggle	Channel
Surfaces
surface	Surface In
surface	Mask
slider	Mix
Palettes
palette	From
palette	To
Comparison
enum	Mode
slider	Threshold
bool	Multiply Alpha
Randomize
slider	Hue Randomize
slider	Sat Randomize
slider	Val Randomize
Replace Others
bool	Replace Other Colors
color	Target Color
Render
bool	Hard Replace
Outputs
surface	Surface Out
Attributes
Color Depth

Do not be confused with Replace Colors the internal name can be very confusing and you should use the display name instead. Replace palette match every color in the surface with the Palette From and replace it with the color on the same index in the Palette To. ## Properties ### Surface In The input surface ### Palette From The palette to match the color with ### Palette To The palette to convert to ### Threshold How much the color can differ from the palette to be match. ### Multiply Alpha Whether to multiply the alpha channel to the color before matching. ### Set Others To Black Whether to set the colors that aren't matched with any color in the palette to black. ### Hard Replace Whether to replace the color with the closest color in the Palette To or to blend base color with the target color based on similarity.

Commit History

Related Links

• Base Code: /scripts/node_color_replace/node_color_replace.gml
• Shader [sh_palette_replace]: /shaders/sh_palette_replace/sh_palette_replace.fsh
